RealBlackStuff wrote:All that those boardviews show are rectangles and dots, no matter how big you try to make them. I don't see any connections, any part-numbers, any text, any indication what a particular rectangle might be.ĭouble-clicking on a dot marks it with a random(?) number, no idea where to go from there.Have you not thought about exploring what the various menu options are? If you can see the board view, then you at least know how to open a file. From there, about the only thing that can go wrong is that you overwrite, if the program allows it, the data file. To prevent that, simply work on a copy of the original file. In any event, hovering over the icons under the menu line will tell you what they do. If there's a hotkey associated with the action, it's also displayed. From left to right:Īll of these actions should all be self-explanatory.
The board view program is used with the associated schematic diagram as the part numbers and signal names are embedded into the.
BDV file matches the schematic sometimes there's different motherboards used in the same model. An example would be one system using Intel graphics, versus another that uses ATI. Open the file and use the Find/Find Component Part (or hotkey D) to enter U42. Why "U42"? That's the part name used in the schematic. Use the Find/Find Net (By Net Name) command and enter smb_data in the first line (caps not sensitive). There's two other lines that you can also specify that will be in GREEN or ORANGE.
This allows you to enter up to three signal paths and they will be shown as the related colors. Tebo IctView Ver:4.0 Tebo-ICT_view_4.0.Click the FIND button and you should see several items now displayed in red. The values for this pin using my multmeter are Ohm 0. Then, I decided to choose a random pin on the board view which is the R9720, Net: BKLISEN4 (logic board K29). Tebo IctView Ver:4.0 Tebo-ICT_view_4.0.zip 0 Comments Current version: 15.22.3.LANDREX TEST LINK ver:1.0 - Currency Euro.That can then be used to program the AOI equipment. PCB PADS 9.5.1 PCB viewer for Apple Iphone/Ipad PADS9_5_1.zip GR GR format viewer BoardView ver.5 BoardView_5.0_GR_1.zip If error 203 appears please restart aplication PCBRepairTool.zip For Windows 7/8 and Windows XP / Vista CADSeeV4-Touch.zip CST IBM LENOVO Card analisis support tool ver:3.32 Castw.zip To open a "Board view" file please use a "Drag & Drop" function. BDV HONHAN BDV BoardViewer BDV-BoardView.zipĪTE BV Boardview ver:1.5.0 The BoardView v1.5 does not support "CTRL+O" or "File>Open" options. IDEAL ELECTRONICS BOARDVIEW SOFT Board_view.zip LANDREX TEST LINK ver:2.2 T-link1_v22.zipĪllegro FREE Physical Viewer VER:15.7 Allegro_Free_Physical_Viewer_15.7.zipĪllegro FREE Physical Viewer VER:16.6 allegro_free_viewer_16-6.zip Test Link BRD Viewer ver:2.2 BRD-T_link01_new_.zip BRD TopTest BoardVIew R4 BoardViewR4.zip ASC ASUS BOARD VIEWER TSICT ver:1.6 ASUS_TSIC.zip
